Connectors etc for the VIC20

Products:

Click on the product thumbnail for an enlarged view.

14 pin DIL socket

14 Pin DIL chip Socket

DIL 14 socket (suitable for 74LS00, 74LS08, 74LS32, 74LS74, 7406, 4066 etc)

Price: £ 0.10   Add to cart. (67 in stock)
16 Pin DIL socket

16 Pin DIL Chip Socket

DIL 16 socket (Suitable for 4116, 4164, 4044, 74LS139, 74LS157, 74LS257, 74LS258 etc)

Price: £ 0.14   Add to cart. (91 in stock)
18 pin DIL socket

18 Pin DIL chip Socket

DIL 18 socket (suitable for LM1889 Video encoder, 41464 RAM chip etc)

Price: £ 0.15   Add to cart. (40 in stock)
20 Pin DIL socket

20 Pin DIL Chip Socket

DIL 20 socket (Suitable for 74LS373 etc)

Price: £ 0.20   Add to cart. (9 in stock)
24 pin DIL socket

24 pin DIL IC Socket

  • As used in the Commodore 64 for the Basic, Kernal and Character ROM chips.
  • Two of these placed end-to-end will replace a 48-pin DIL socket such as that for the ULA in the Spectrum 128
Price: £ 0.35   Add to cart. (21 in stock)
28 Pin DIL Socket

28 Pin DIL Socket

  • Suitable for for ROM in Spectrum, SID and PLA chips in the Commodore 64
Price: £ 0.39   Add to cart. (30 in stock)
40 Pin DIL Socket

40 Pin DIL Chip Socket

  • As used for Z80 (and ULA on Spectrum 16/48) , CPC464 and the CPU, VIC-II, CIAs on Commodore 64
Price: £ 0.42   Add to cart. (19 in stock)
C64 Serial / Disk Drive socket (also for C16,+4, Vic20)  - 6 pin DIN *NEW*

Serial / IEC Disk Drive connector (6 pin DIN socket)

  • Brand new C64 serial port PCB socket
  • Also used on the C16, Commodore +4 and VIC20
Price: £ 0.99   Add to cart. (9 in stock)
C64 Video socket  - Early Breadbin 5 pin DIN *NEW*

Audio / Video socket : 5-pin DIN for early Commodore 64s & VIC20

  • A brand new 5-pin DIN socket as used on very early breadbin C64 boards and the VIC20
Price: £ 1.50   Add to cart. (10 in stock)
Commodore 64 Joystick port - Salvaged

Joystick connector for Commodore 64 and other computers

  • Salvaged part, removed from a breadbin style C64.
  • Clean, undamaged (pins are not corroded) and in good working order.
  • Supplied with screws.
  • Also used in the "short board" VIC20
  • Can be used on the spectrum 128 +2 and Amstrad CPC 464 (using the screws to hold it in place instead of the clipping lug).
Price: £ 2.50   Add to cart. (3 in stock)
Power switch for Commodore 64 ** NEW ***

Power switch for Commodore 64 ** New **

  • A brand new power switch for C64, C64C, VIC20 (the version with a round DIN-style power plug), C128 (but not D/DCR versions), 1541-II, 1581 and also CD32.
Price: £ 4.99   Add to cart. (9 in stock)
SCART plug

SCART Plug

Brand new  - suitable for making up TV cables etc

Price: £ 1.95   Add to cart. (2 in stock)
VIC20 early style side port panel

VIC20 early style side port panel

  • For VIC20s that have a 2-pin power socket.
  • Note the socket is attached (desoldered from the choke) due to the difficulty in removing it.
  • Good conditon - All text intact
  • Screws are supplied
Price: £ 6.50   Add to cart. (1 in stock)
