Connectors / Sockets for ZX81 MotherboardProducts:
Click on the product thumbnail for an enlarged view.
24 pin DIL IC Socket
- As used in the Commodore 64 for the Basic, Kernal and Character ROM chips.
- Two of these placed end-to-end will replace a 48-pin DIL socket such as that for the ULA in the Spectrum 128
3.5mm Jack Plug for ZX81 PSU
- A high quality (not the ubiquitous cheap versions widely available) slim profile jack plug suitable for replacing those found on ZX81 power supplies.
40 Pin DIL Chip Socket
- As used for Z80 (and ULA on Spectrum 16/48) , CPC464 and the CPU, VIC-II, CIAs on Commodore 64
Spectrum Ear / Mic (and ZX81 Power) connector
The mic / ear sockets on the Spectrum (and ZX81) can become loose / corroded over the years making tape connection intermitent.
- Brand new direct replacement socket.
- Also used in the "Toastrack" 128 and for Power-in / Ear / Mic in the ZX81
Keyboard membrane connector - 5 way type (Left side)
- For original Spectrum, ZX81 and "Toastrack" 128
- Brand new
Keyboard membrane connector - 8 way type (right side)
- For original Spectrum, ZX81 and "Toastrack" 128
- Brand new
|
