C64 Cables
Internal and external wiring associated with the C64 Products:
Click on the product thumbnail for an enlarged view.
Original RED Power LED cable for breadbin C64
- Original red Commodore 64 power LED with cable, plug and original grommet
- Also used in VIC 20
- Includes the original black fitting grommet
- Not suitable for the later white C64C since that uses a rectangular LED
- Note: Cable is approx 25CM long - some versions of the C64 (GS, Aldi) require a longer cable - please check.
- I also have new LED cables with red, green or blue LEDs - please see the C64 mods section.
Custom BLUE Power LED cable, for Breadbin C64
- A new, blue Commodore 64 power LED with cable, plug and grommet for custom case jobs
- For breadbin case C64 (can also be used in VIC 20)
- Not suitable for the later white C64C since that uses a rectangular LED
- Note: Cable is approx 45CM long so is suitable for "Breadbin" and "Aldi" model C64s)
Custom GREEN Power LED for Breadbin C64
- As above but with a green LED
Custom RED Power LED for breadbin C64
- As above but with a red LED.
New power LED *BLUE* for C64C with short cable
- New, rectangular BLUE power LED cable+connector for C64C case.
- Short (~14cm) cable so only suitable for the common "short" C64C PCBs with the LED connector towards the top left (not the transititional board p/n 250466 or any "breadbin" board - see below for those.)
New Power LED *BLUE* assembly for C64C with long cable
- A new non-original BLUE rectangular power LED with connector for C64C
- Same diffused white lens LED style as original but LED lights up blue.
- Not suitable for "breadbin" C64 (which has a 5mm round LED - see below for those).
- Cable is approx 45cm long - so suitable for all boards
- Original standard green / red C64C LED cables are listed below if required
New Power LED *GREEN* for C64C with long cable
- A new non-original GREEN rectangular power LED with connector for C64C
- Same diffused white lens LED style as original but LED lights up green.
- Not suitable for "breadbin" C64 (which has a 5mm round LED - see below for those).
- Cable is approx 45cm long - so suitable for all boards
- Original standard green / red C64C LED cables are listed below if required
New Power LED *GREEN* for C64C with short cable
- A new non-original Green rectangular power LED with connector for C64C
- Same diffused white lens style as the original types.
- Not suitable for "breadbin" C64 (which has a 5mm round LED - see below for those).
- Cable is approx 14cm long - so only suitable for short boards that have the LED connector in the top left.
- Original standard green / red C64C LED cables are listed below if required
New Power LED *RED* for C64C with long cable
- A new (non-original) Red/Orange rectangular power LED with connector for C64C
- Same diffused white lens LED style as original but LED lights up red/orange
- Not suitable for "breadbin" C64 (which has a 5mm round LED - see below for those).
- Cable is approx 45cm long - so suitable for all boards
- Original standard green / red C64C LED cables are listed below if required
New Power LED *RED* for C64C with short cable
- A brand new (non-original) Red/Orange rectangular power LED with connector for C64C
- Same diffused white lens style as original types.
- Not suitable for "breadbin" C64 (which has a 5mm round LED - see below for those).
- Cable is approx 14cm long - so only suitable for short boards that have the LED connector in the top left.
- Original standard green / red C64C LED cables are listed below if required
New power LED *WHITE* for C64C with long cable
- A new custom WHITE rectangular power LED with connector for C64C
- Same diffused white lens style as the original types.
- Not suitable for "breadbin" C64 (which has a 5mm round LED - see below for those).
- Cable is approx 45cm long - so suitable for all C64C cases and motherboard combos.
New Power LED *WHITE* for C64C with short cable
- A new custom WHITE rectangular power LED with connector for C64C
- Same diffused white lens style as the original types.
- Not suitable for "breadbin" C64 (which has a 5mm round LED - see below for those).
- Cable is approx 14cm long - so only suitable for short boards that have the LED connector in the top left.
Original GREEN power LED assembly for C64C with short cable
- Original, rectangular GREEN power LED with connector for C64C
- Standard ~14cm cable so only suitable for the common "short" C64C PCBs with the LED connector towards the top left.
- Not suitable for "breadbin" C64 (see below for those).
Original RED Power LED assembly for C64C with short cable
- As above but with red LED
- Standard ~14cm cable, so only suitable for the "short" C64C boards with the LED connector in the top/left.
Original Sinclair issue RF TV Cable
- A 2 Metre long RF cable for connecting Spectrum / C64 etc to a TV aerial socket
- As originally supplied with the ZX Spectrum.
- Cleaned and tested
Bi-colour rectangular LED for Ultra 64 PCB in *C64C case*
- A bi-colour* (red/green) rectangular power LED suitable for the Ultra 64 PCB in a C64C case
- Common cathod LED with series resistors on the two LED anodes to balance their brightness.
- The header plug can be fitted either way around, it just flips the red/green (which can also be set up in the Ultra C64 config settings).
- (*If both LEDs are activated, the LED lights up yellow.)
Bi-Colour 5mm Round LED for Ultra64 PCB in *breadbin* case
- 5mm round Red/Green LED with diffused lens suitable for Ultra 64 in Breadbin Case (Red-Gnd-Green 3pin Connector)
- A new fitting grommet is included
- Common cathod LED with series resistor to balance the brightness of the red/green sides.
- The header plug can be fitted either way around, it just flips the red/green (which can also be set up in the Ultra C64 config settings).
- (*If both LEDs are activated, the LED lights up yellow.)
|
